Garfil Rocky Twisted Net

Application:

Specifically designed for mouth portion of rocky bottom trawl

High abrasion/ chafing resistance even in rocky surfaces		Good mouth opening		Good knot breaking strength
No mud ingress, hence not heavy.

PRODUCT SPECIFICATIONS
Twine Size (mm)	Twine Size (Ply)	Mesh Size in mmkk
		From	Upto
ROCKY 2	18 Ply  (1.25mm)	100	3000
ROCKY 3	18 Ply  (1.25mm)	100	3000
ROCKY 4	24 Ply  (1.50mm)	100	3000
ROCKY 5	36 Ply  (2.00 mm)	100	3000
ROCKY 7	63 Ply  (2.50 mm)	100	3000
ROCKY 8	63 Ply  (2.50 mm)	100	3000
ROCKY 13	117 Ply (3.00 mm)	100	3000
Note :- * Specific orders above 3000 mm can be taken.

* the above specifications are indicative and are likely to change

Garfil NEST

Specially designed for codend of shrimp and fish trawl.

Benefits:

1. 1. Uniform mesh size
2. 2. Smoother inner surface – Less Fish Damage
3. 3. Lighter in weight in comparison with Knotted Codend

Garfil RUNNER

Designed for optimal performance in belly portion (20mm-200mm) of fish trawl net
Benefits:

• Down sized twine
• Better water flow
• Less drag
• Higher speed
• Better mouth opening
• Lower weight

PRODUCT SPECIFICATIONS
Twine Size (mm)	Twine Size (Ply)	Mesh Size in mmkk
		From	Upto
1.00	5X3 Ply	20	200
1.25	6X3 Ply	20	200
ROCKY 4	24 Ply  (1.50mm)	100	3000
1.50	8X3 Ply	20	200
2.00	12X3 Ply	25	200
2.10	15X3 Ply	26	200
2.25	18X3 Ply	26	200
2.50	21X3 Ply	26	200
3.00	39X3 Ply	60	200
